The electrolyzer consists of many cells.Each cell consists of cathode pool,which are separated by the membrane.The electrolyte will circle through cathode pool and anode pool with circle pump. Cells are connected by conductors.or coppers. The electrolyte and membrane will conduct between cathode pool and anode with series mode.Oxidation will happen at the anode with oxidation products and deoxidation will happen at the cathode with deoxidation products
Qinhuang is professional manufacture for electrolytic cell. We have 5 types hot cell Electrolyzer for acid water application
![]() |
16Type-1
Dimensions:240×180×95 mm |
![]() |
16Type-2 Dimensions:295×155×115mm Water out index:pH<2.7 Water capacity:300L/h Power range:0~700W Power factor:≧0.85 Input current:DC,0~32 A Input voltage:DC,0~18V Outlet pipe:DN1/2 Inlet pipe:DN1/2 |
![]() |
8Type-2 Dimensions:240×95×100 mm Water out index:pH<2.7 Water capacity:150L/h Power range:0~500W Power factor:≧0.9 Input current:DC,0~25 A Input voltage:DC,16~24V Outlet pipe:DN3/8 Inlet pipe:DN3/8 |
![]() |
8Type1
Dimensions:231×96×45 mm |
![]() |
20Type-1 Dimensions:300×150×100 mm Water out index:pH<2.7 Water capacity:300L/h Power range:0~1200W Power factor:≧0.85 Input current:0~50 A Outlet pipe:DN3/8 |
