Water Electrolysis
0~1000A
2.8~13
Platinum coating+Gr1 titanium
Availability: | |
---|---|
MMO Mesh Electrode are made using expanded titanium plate,which are coated with platinum.The Pt is thermally applied to the titanium mesh substrate to form an extremely chemical-resistant coating.This special composition brings together the stability of titanium with the conductive properties of platinum to achieve superior performance.
Name | Water electrolysising platinum coating gr1 titanium plate electrode |
Substrate material | Pure Titanium Gr1/Gr2 |
Coating material | Platinum |
Current density | < 20000 A/M2 |
Nobel metal content | 15 g/M2—100 g/M2 |
Shape | Different dimension and shape is available |
Content of florin ions | < 50 mg/L |
pH value | 1—14 |
Enhanced life | 40k mA/M2, 1 mol/L H2SO4, h=1200 h |
MOQ | 1 Piece,sample order available |
- Selected TA1 titanium plate,After sandblasting, leveling, die stamping, bump welding, pickling, sintering, etc.
- Uniform sandblasting, electrode column and substrate are firmly welded,Good conductivity, no cloak, no welding slag, no damage.
- Water ionizer
- Sterilization machine
- Super acid water machine
- Super alkaline water machine
- Sodium hypochlorite generator
MMO Mesh Electrode are made using expanded titanium plate,which are coated with platinum.The Pt is thermally applied to the titanium mesh substrate to form an extremely chemical-resistant coating.This special composition brings together the stability of titanium with the conductive properties of platinum to achieve superior performance.
Name | Water electrolysising platinum coating gr1 titanium plate electrode |
Substrate material | Pure Titanium Gr1/Gr2 |
Coating material | Platinum |
Current density | < 20000 A/M2 |
Nobel metal content | 15 g/M2—100 g/M2 |
Shape | Different dimension and shape is available |
Content of florin ions | < 50 mg/L |
pH value | 1—14 |
Enhanced life | 40k mA/M2, 1 mol/L H2SO4, h=1200 h |
MOQ | 1 Piece,sample order available |
- Selected TA1 titanium plate,After sandblasting, leveling, die stamping, bump welding, pickling, sintering, etc.
- Uniform sandblasting, electrode column and substrate are firmly welded,Good conductivity, no cloak, no welding slag, no damage.
- Water ionizer
- Sterilization machine
- Super acid water machine
- Super alkaline water machine
- Sodium hypochlorite generator
