The principle and operation of sodium hypochlorite generator

Views: 40

Working principle of sodium hypochlorite generator

The sodium hypochlorite generator is a set of devices that generate a sodium hypochlorite generator solution by electrochemical reaction of low-concentration salt water through energized electrodes.

Basic operation process of sodium hypochlorite generator

When working, first turn on the power supply, the sodium hypochlorite generator will add ordinary industrial salt (about 0.35 yuan per kilogram) into the salt chemical device and dissolve it into about 10% salt water, open the valve to let the salt water enter the salt storage tank through filtration and sedimentation; then, Start the self-dispensing switch, and the equipment will automatically mix brine to dilute brine with a concentration of about 3.5%; then open the valve to adjust the flow meter, so that the mixed brine can pass through a set of cathode and anode tubes according to the set flow rate. ; Sodium hypochlorite generator Finally, start the rectifier current switch, and open the cooling water valve to cool the electrolytic cell, and the sodium hypochlorite generator starts to work. In this way, the whole equipment produces a standard sodium hypochlorite generator liquid (concentration is about 1%); finally, the liquid medicine automatically flows into the liquid storage tank, which is convenient for storage and dosing at any time.

Backwashing: After each shift is completed, it must be backwashed once. When backwashing, first open the empty valve to drain the salt water accumulated in the pipeline, and then open the backwash vent and the water inlet valve of the backwash water inlet, and rinse for about 10 minutes. , and then open the vent valve to drain the accumulated water and use it next time.

Pickling: The generator needs to be pickled once for a total of 250 hours of operation. The pickling cycle should be extended or shortened according to the water quality. When pickling, first open all the emptying valves to drain the accumulated brine in the pipeline, and then open the acid inlet valve. and the acid outlet valve, until the acid water flows out from the organic pipe of the acid outlet and venting pipe, close the acid inlet valve, wait for the acid water to soak in the electrode tube for 1-2 hours, then drain the acid water, and then backwash it again. The concentration of diluted hydrochloric acid is about 10%.

Matters needing attentiondisinfectant water machine price - qinhuangwater

①In general automatic operation, there is no need for special personnel to manage it. It can work for (7-10) days once salt is added. It will automatically stop and alarm when there is a lack of salt water. When salt is added, the generator must be backwashed once.

②When the equipment is running, it is strictly forbidden to run without cooling. In case of water failure in the unit, it is strictly forbidden to use the equipment.

③ Regularly check whether the power connection bolts are loose and generate heat, and whether the filter net in the high-level salt tank is blocked, and remove them in time.

④ Try to avoid fireworks indoors, maintain good ventilation, and be equipped with part-time staff for management.

4. The sterilization and virus killing principle of the sodium hypochlorite generator roughly has the following three modes of action:

The main mode of action of the sodium hypochlorite generator is to form hypochlorous acid through its hydrolysis, and the hypochlorous acid is further decomposed to form new ecological oxygen [O]. Such substances are denatured, and the sodium hypochlorite generator will cause the death of pathogenic microorganisms. In fact, the principle of chlorine disinfection is mainly to generate hypochlorous acid and then release new ecological oxygen [O].

According to chemical measurements, the sodium hypochlorite generator with PPM concentration is almost completely hydrolyzed into hypochlorous acid in water, and the efficiency of the sodium hypochlorite generator is higher than 99.99%. The process can be simply represented by the chemical equation as follows:

NaClO + H2O = HClO + NaOH

HClO → HCl + [O]

Secondly, in the process of sterilization and virus killing of hypochlorous acid, the sodium hypochlorite generator can not only act on the cell wall and virus shell, but also because the hypochlorous acid molecule is small and has no charge, it can also penetrate into the body of bacteria (viruses) and interact with bacteria (viruses). Virus) body proteins, nucleic acids, and enzymes and other organic macromolecules undergo oxidation reactions, and the sodium hypochlorite generator kills pathogenic microorganisms.

R-NH-R + HClO → R2NCl + H2O

At the same time, the chloride ions produced by hypochlorous acid can also significantly change the osmotic pressure of bacteria and virions, and the sodium hypochlorite generator makes the cells inactive and die.

In addition, the sodium hypochlorite generator can also decompose trace pesticides remaining on agricultural and sideline products such as vegetables and fruits. Most pesticides are composed of organic substances, and the new oxygen released by the sodium hypochlorite generator can oxidize and decompose these substances. Sodium hypochlorite generator undoubtedly has a major role in promoting the development of modern agriculture and fruit and vegetable packaging industry.

It is also worth affirming that since the disinfectant produced by the sodium hypochlorite generator does not produce free chlorine in the water like disinfectants such as chlorine gas and chlorine dioxide, it is generally difficult to form carcinogens that are unfavorable to human health due to the presence of free chlorine. ; Unlike ozone, as long as there is a very weak amount (0.001mg/m3) in the air, it will cause damage and poison to life; moreover, it will not form hydrochloric acid as chlorine reacts with water. Severe corrosion of the pipes.
