Functions
Making hydrogen Hydrogen Purity Smart indicator Safety setting Low noise
water 99.99%
Suitable for Hydrogen-oxygen Hydrogen flow rate: Water flow detection
all people separated 300/600ml per minute
technology
How to use
Step 1: Open the lid, fill pure water into the inner water tank till it reaches the maximum water line.
Step 2: When you use this device for the first time, please open the drain valve to allow some water to flow out and ensure the water stays above the minimum water line.
Step 3: Connect the device to the power supply and connect the inhalation tube.
Step 4: Press the button on the top to start the machine.
Parameter
Product Name | Hydrogen Inhalation Machine |
Model | EHM-H600-D |
Size | 320×310×254mm |
Net Weight | 12kg |
Water Tank Volume | 2L |
Hydrogen purity | 99.999% |
Rating Voltage | 220V/50Hz |
Output Pressure | 0.2Mpa |
Function | Hydrogen Inhalation |
Rating Power | 150/300W |
Product performance standard: T/GDID 1009-2018
Daily Maintenance
l When the machine works continuously for more than 1 week, it is recommended to replace the water inside with some new water.
l When the machine is not used more than one week, please drain the water inside and add new water.
l When the water quality is poor, output hydrogen may reduce, and the pipe may be blocked by the scale, leading to a shorter service life of the machine. So please use pure water as requested.
Trouble Shooting
Problems | Possible Reasons | Solutions |
The machine can not start. | 1.The power cord plug is not plugged properly. 2.The ON/OFF button is not pressed. | 1. Make sure the power cord plug and the socket are in full contact. 2. Press the ON/OFF button when the power is on. |
No hydrogen comes out. | 1. The inner water tank lacks water. 2. The inhalation tube is not connect properly. 3. The gas-water separator inside does not work normally. | 1. Add pure water up to the maximum water line. 2. Connect the inhalation tube properly. 3. Please contact the after-sales center. |
Abnormal display data | 1. The electrolytic cell has water scale. 2. The monitor is abnormal.
| Please contact the custom service representative to confirm the failures, and send the machine to our service center. |
Notice
l The water added into the inner tank must be pure water or distilled water.
l Please add the water up to the maximum water line before start the machine.
l When the machine works continuously for more than one week, it is recommended to drain the water inside and replace with some new water.
l If the user does not use pure water as requested, leading to the machine failure, it is not covered by warranty.
l Please use the power outlet correctly. Cut off the power supply during maintenance and transportation.
Warranty Rules
We offer 12 months warranty from the date of the goods receipt.
Please keep the purchase voucher properly. If you need service during warranty period, please contact our after-sales center.
Non-warranty Rules
The following items are not within warranty.
l It has exceeded the warranty period.
l Failures caused by human factors, including but not limited to improper installation, use and maintenance.
l Outer packaging, accessories, gifts, and user manual are not complete. The user loses the purchase voucher.
l Failures or damages caused by force majeure, such as earthquake, fire, flood, lightning strike
l Improper use, maintenance, collision, change, disassembling unauthorized by Guangdong Cawolo Health Technology CO., Ltd.
